2024 Yamaha UMAX 2 RALLY EFI Service and Repair Manual

In the 2024 UMAX book, LIT-19616-A3-12, the Rally EFI two-passenger car appears under code YUM2A24_UMXS.

Eight configurations from that model year are covered together. The EFI chapters apply to the injected cars, and Yamaha marks which codes each procedure belongs to, which is worth noting when a page shows two variations.

Fuel system coverage includes fault codes, circuit and component tests and fuel pressure checks. Engine service runs from removal through reassembly with the clearances and torque figures needed. Clutch and drive belt, ignition, charging and starting, brakes, steering, suspension, wheels and body panels all have their own sections, and the wiring diagrams are complete.

Before ordering parts, match YUM2A24_UMXS to the vehicle identification and quote LIT-19616-A3-12 alongside it.

Torque figures and wear limits sit in tables rather than buried in the text, which makes them quick to find with the car apart on the bench and a fastener in your hand.
