2024 Yamaha SRX120R Service and Repair Manual

The 2024 SRX120R carries the code SRX1NRL. Its factory service manual is Yamaha LIT-12618-03-98, issued for that model year by itself.

Procedures follow the dealer sequence — inspect and measure, remove, replace, torque to the stated figure — and every specification in the tables belongs to this sled alone. Engine mechanical, clutch and drive train, track tension and alignment, suspension, brakes and the electrical system with its wiring diagram are all documented, as are Yamaha's maintenance intervals.

Owners of a youth machine often end up doing the work themselves simply because the sled is small and the jobs are short. The value of the book is that it replaces judgement with numbers on the parts where that matters.

Confirm SRX1NRL before ordering.
