2024 Alfa Romeo Tonale Service and Repair Manual

This factory service and repair manual for the 2024 Alfa Romeo Tonale covers two powertrains in a four-door sport utility. One is a plug-in hybrid built around a turbocharged 1.3-liter inline-four of 81 cubic inches; the other is a turbocharged 2.0-liter inline-four of 122 cubic inches. Both use dual overhead camshafts and gasoline. Five trims are listed: Speciale, Sprint, TI, TI Hibrido and Veloce. Procedures, specifications, torque values, wiring diagrams and diagnostics address the engines, the plug-in hybrid system, fuel, cooling, transmission, brakes, suspension, steering, electrical system and body.

Engines covered

• 1.3L inline-four plug-in hybrid (81 cu in) — DOHC, turbocharged, gasoline
• 2.0L inline-four (122 cu in) — DOHC, turbocharged, gasoline

Body styles covered

• 4-door sport utility

Trims covered

• Speciale
• Sprint
• TI
• TI Hibrido
• Veloce

Known issues on the 2024 Tonale. NHTSA lists 8 recalls for the 2024 Tonale. On certain 2024 Tonale plug-in hybrid vehicles, the 12-volt battery positive cable or the high-voltage connector cable might not have been tightened properly, and the connection could overheat into a fire; owners were told to park outside until dealers had inspected the connections and, where needed, tightened them. A second recall concerned certain 2024 Tonale plug-in hybrid vehicles whose brake pedal could fold under the driver's foot and leave the car without braking; that campaign covered 5,974 vehicles, and dealers strengthened the pedal arm. A third, on certain 2024 Tonale vehicles, concerned rear outboard seat belts that could twist and fail to retract. Of 10 owner complaints, 3 apiece name the electrical system, engine, forward collision avoidance and service brakes, and 1 fuel/propulsion. 2 complaints reported a crash. This manual gives the brake, electrical and plug-in hybrid systems procedures, specifications, torque values, wiring diagrams and diagnostics.
