2023 Yamaha WOLVERINE RMAX4 XT-R Service and Repair Manual

$29.99 USD
Digital manual — nothing ships
Matched to your exact vehicle
Money-back guarantee, pay once
4.5 · Trusted by 800+ mechanics & DIYers
Buy 2+ manuals, save 20% Discount applied automatically at checkout
20% off

Owners of the 2023 RMAX4 XT-R, code YXF10WRZPT, want Yamaha part LIT-11616-35-22.

Yamaha issued that manual for the 2022 to 2024 run and wrote the RMAX4 LE and R-Spec into it as well. The advantage in practice is that a job you are doing is described once, in full, rather than summarised differently in three separate books.

Using the manual

Work through it as a technician would: find the system, follow the removal sequence, measure what the procedure tells you to measure, then reassemble to the torque figures given. Wiring diagrams show the harness as delivered, and the diagnostic sections take a reported symptom as their starting point.

Confirm the model code against the plate on your machine before ordering.
