2023 Yamaha SRX120R Service and Repair Manual

$29.99 USD
Digital manual — nothing ships
Matched to your exact vehicle
Money-back guarantee, pay once
4.5 · Trusted by 800+ mechanics & DIYers
Buy 2+ manuals, save 20% Discount applied automatically at checkout
20% off

Yamaha's service manual for the 2023 SRX120R is part number LIT-12618-03-92, and the sled itself is identified as SRX1NPL.

Coverage is single-year, which keeps the specification tables unambiguous. Engine service comes with torque sequences and wear limits, the clutch and drive sections document the whole assembly rather than summarising it, and track, suspension and brake adjustment each have their own procedures. Wiring diagrams are included in full for electrical faultfinding.

The periodic maintenance chapter is the one a parent will open most. Yamaha's intervals account for a machine that is used hard in short bursts and then stored, which is exactly how most of these sleds live.

Verify SRX1NPL on your machine before ordering.
