2023 Yamaha DRIVE2 ADVENTURER SPORT 2+2 (CAMP) AC IRS Service and Repair Manual

DR2E23_CAMP identifies the 2023 DRIVE2 ADVENTURER SPORT 2+2 (CAMP) AC IRS. Yamaha's service book for it is LIT-19616-A0-31.

2023 closes out the four model years that volume covers. Twenty-five Drive2 machines are in it, so the AC IRS car sits next to the EFI Quietech models, the lithium fleet cars and the PowerTech AC PTV, with shared procedures written once.

Coverage highlights

• PowerTech AC motor and controller testing with expected values
• Battery set, charger and harness, plus wiring diagrams
• Independent rear suspension, axle and alignment
• Brakes, park brake, steering, wheels and tyres
• CAMP rear seat, grab rails and body panels
• Maintenance intervals and full specification tables

This is the material Yamaha dealers work from, which means measurements and torque figures rather than general advice. Confirm DR2E23_CAMP on the plate of your own car first.
