2022 Yamaha SIDEWINDER SRX LE Service and Repair Manual

Service data for the 2022 SRX LE, model code SW1NSRLNW, was published by Yamaha as part number LIT-12618-03-86.

That number also answers for the 2022 L-TX GT EPS, L-TX LE, L-TX SE, S-TX GT EPS, X-TX LE and X-TX SE, since the factory wrote the season's Sidewinder models into a single manual. Common assemblies are covered once; where a figure belongs to one model only, the code identifies it.

Expect the working content of a dealer manual. Disassembly and reassembly are laid out step by step, with clearances, service limits and torque values in place rather than left to judgement. The electrical chapters carry full wiring diagrams and connector references, and faults are traced through charts organised by symptom instead of by component.
