2022 Yamaha MOUNTAIN MAX LE 154 Service and Repair Manual

Four 2022 machines share LIT-12618-03-85: the Mountain Max LE 154, the LE 154 SL, the LE 165 and the Transporter 800. The sled documented on this page is the LE 154, model code MM8N54ENS.

Having the four in one volume means the book spends its pages on the systems rather than repeating itself, and it flags by model code the places where the machines part company — track length, suspension settings, and the components that follow from them.

Practical use looks like this: symptom in the troubleshooting chart, circuit or assembly identified, removal sequence followed, part measured against the printed limit, reassembly to the specified torque. Wiring diagrams cover the electrical side in full, and the maintenance schedule gives intervals in both distance and hours where Yamaha specified them.

Check the code on the machine against MM8N54ENS before ordering.
