2020 Yamaha UMAX 1 RALLY EFI Service and Repair Manual

$29.99 USD
Digital manual — nothing ships
Matched to your exact vehicle
Money-back guarantee, pay once
4.5 · Trusted by 800+ mechanics & DIYers
Buy 2+ manuals, save 20% Discount applied automatically at checkout
20% off

The 2020 UMAX 1 Rally EFI is coded YUM1A20_UMXS, and its service information is Yamaha LIT-19616-SR-20.

That book is narrow by design: two 2020 Rally models, nothing else. Where the wider UMAX manuals hedge across many configurations, this one addresses the Rally as built for that single model year.

Work covered runs from periodic maintenance through engine and fuel injection service, ignition and charging tests, clutch and drive belt inspection, brake and parking brake adjustment, steering and suspension, and the wiring diagrams. Fault diagnosis on the injection system follows the factory sequence of reading the code, testing the circuit, then replacing.

Quote both the part number and the YUM1A20_UMXS code when checking a parts listing, since Rally-specific components do not always interchange with the standard UMAX.
