2020 Yamaha AR195 Service and Repair Manual

The 2020 AR195 is identified by code TP1800A-V, and Yamaha covers it in service manual LIT-18616-03-87.

That book has a long life: 2019 through 2026, taking in the AR190 and AR190 California, the SX190, SX190 California and the SX195. Since the boats share their hull and jet drive, the factory wrote shared procedures once and keyed the exceptions to the model code, which is why the plate reading comes before the parts order.

Included work

• Engine teardown, measurement against wear limits, reassembly torque
• Jet pump, impeller, wear ring, nozzle and reverse gate
• Fuel, cooling and exhaust service
• Hull, deck hardware and bilge system
• Electrical diagnosis with complete wiring diagrams

It is dealer-level material, written for someone doing the job properly.
