2019 Yamaha UMAX RALLY 2+2 (EFI) Service and Repair Manual

$18.00 USD
Digital manual — nothing ships
Matched to your exact vehicle
Money-back guarantee, pay once
4.5 · Trusted by 800+ mechanics & DIYers
Buy 2+ manuals, save 20% Discount applied automatically at checkout
20% off

Code YUM2A19_UMXSCG identifies the 2019 Rally 2+2 with EFI power. Yamaha's manual for it, LIT-19616-TR-19, was written for that model on its own.

Fuel injection diagnosis sits at the front of the drivetrain work: fault code retrieval, sensor and actuator testing, fuel pressure and pump checks. Engine coverage runs from removal through overhaul with clearances and assembly torques, and ignition, starting and charging are handled as measurements against expected values.

Chassis sections cover brakes and parking brake, steering, front and rear suspension, wheels and rear axle, plus the 2+2 rear seat and body panels. Complete wiring diagrams are included.

Confirm YUM2A19_UMXSCG on the vehicle identification, and keep the part number to hand when cross-referencing parts.

The single-model coverage also means the specification tables are short. Every value on the page belongs to this car, with no need to trace which trim a figure was written for.
