2019 Yamaha SRX120R Service and Repair Manual
- Digital manual
- Matched to your model
- Pay once — yours to keep
- 180-day refund guarantee
2019 Yamaha SRX120R Service and Repair Manual
With the R suffix came a new code, SRX1NKL, and a manual of its own: Yamaha LIT-12618-03-56 for the 2019 model year.
The book is the dealer service volume. Engine work is documented with torque figures and wear limits, the clutch and drive arrangement has its own chapter, and track, suspension and brake adjustment are each given as procedures with specifications attached. The electrical section includes the wiring diagram in full.
Since it covers one year only, nothing in the tables belongs to another machine — a small convenience, but a real one when you are checking a fastener torque with the part already in your hand.
Confirm SRX1NKL on the sled before ordering, because the SRX120R ran several seasons and each has a different code and part number behind it.
