2019 Ford Flex Service and Repair Manual

This factory service and repair manual for the 2019 Ford Flex closes out the listing with the familiar pairing of a naturally aspirated 3.5L V6 (213 cu in) and a turbocharged V6 of the same displacement, both dual-overhead-cam gasoline engines, in a four-door sport utility sold as Limited, SE and SEL. Every system in the vehicle is documented the same way, with procedures, specifications and torque values for the mechanical work and wiring diagrams and diagnostics for the electrical side of it.

Engines covered

• 3.5L V6 (213 cu in) — DOHC, naturally aspirated, gasoline
• 3.5L V6 (213 cu in) — DOHC, turbocharged, gasoline

Body styles covered

• 4-door sport utility

Trims covered

• Limited
• SE
• SEL

Known issues on the 2019 Flex. Four recalls are on federal record. One concerns power supply cables at the starter and the alternator that may not have been secured properly, which can arc and start a fire. Two separate campaigns cover a rearview camera that may show a blank or distorted image. The fourth involves B-pillar door trim that can detach while driving. Owners have filed 243 complaints with NHTSA, dominated by back-over prevention, then the structure and the electrical system. Charging circuit wiring, camera diagnostics and trim attachment all belong to this manual's coverage.
