2016 Yamaha SR VIPER RTX LE Service and Repair Manual

Anyone servicing an RTX LE from 2016 should start by confirming two numbers: the sled's model code, SR10RLGL, and the part number of the manual that covers it, LIT-12618-03-26.

What you get is Yamaha's own shop material. Procedures are sequenced the way a technician works — inspect, measure against the limit, remove, replace, torque to figure — and the electrical section includes the wiring diagram rather than a simplified sketch.

That single part number covers the rest of the 2016 Viper line as well: LTX, MTX in its 141, 153 and 162 lengths, RTX DX and SE, the STX DX pair, and the XTX trims. Yamaha wrote one volume because the machines are built from common assemblies, and the tables call out where the LE differs. Keep the code beside you when you reach those tables; it is the fastest way to be sure the figure in front of you belongs to your sled.
