2016 Yamaha ADVENTURER TWO (48V - AC MOTOR) Service and Repair Manual

For 2016 the Adventurer Two AC car is coded YTF2EX6, and the factory manual remains LIT-19616-29-14, which Yamaha wrote to cover model years 2015 through 2018.

Read the code first, because the specification tables inside are separated by year even though one book serves all four. Once matched, the AC drive chapters give controller and motor testing, throttle and sensor input values, contactor checks, regen braking operation and charging system diagnosis, along with the controller fault indications and what each one points to.

The mechanical half covers rear gearcase and axle service, brake adjustment, steering and front suspension, wheel and tyre data, and frame and body fasteners, all with factory torque specifications. Year-specific wiring diagrams are included.

Confirm YTF2EX6 on the identification plate before ordering.
