2016 Volkswagen Caddy Service and Repair Manual

This factory service and repair manual for the 2016 Volkswagen Caddy addresses the 4-door mini passenger van, listed in Base and Maxi trims. Motivation comes from a 73-cubic-inch (1.2L) inline-four that is turbocharged, gasoline-fueled and fitted with an SOHC valvetrain. Engine, fuel, ignition and cooling systems are supported with procedures and specifications, the transmission, brakes, suspension and steering with torque values, and the electrical system with wiring diagrams and diagnostics.

Engines covered

• 1.2L inline-four (73 cu in) — SOHC, turbocharged, gasoline

Body styles covered

• 4-door mini passenger van

Trims covered

• Base
• Maxi

Known issues on the 2016 Caddy. As a 4-door mini passenger van, the 2016 Caddy gets body and electrical procedures for that body style. Up front, the turbocharged 1.2L gasoline engine is backed by specifications and diagnostics for fuel delivery, ignition and cooling. The transmission and drivetrain carry procedures and torque values, and the brakes, suspension and steering are handled the same way, with wiring diagrams covering the electrical system of the Base and Maxi.
