2016 Ram ProMaster 1500 Service and Repair Manual

This factory service and repair manual for the 2016 Ram ProMaster 1500 documents the Base 4-door standard cargo van. Its engine list names a 3.6L V6 displacing 220 cubic inches, naturally aspirated with dual overhead cams and rated for flex-fuel or gasoline, alongside a 3.0L inline-four turbodiesel of 183 cubic inches, also DOHC. Specifications, procedures and wiring diagrams cover both powerplants and the transmission, brakes, steering, suspension and electrical system of the van.

Engines covered

• 3.0L inline-four (183 cu in) — DOHC, turbocharged, diesel
• 3.6L V6 (220 cu in) — DOHC, naturally aspirated, flex-fuel or gasoline

Body styles covered

• 4-door standard cargo van

Trims covered

• Base

Known issues on the 2016 ProMaster 1500. With a gasoline or flex-fuel V6 on one side and a turbodiesel four on the other, the manual gives the 2016 ProMaster 1500 procedures, specifications, torque values and diagnostics for both engines, including their fuel and cooling systems. Beneath the 4-door standard cargo van body sit the transmission, drivetrain, brakes, steering and suspension, which are covered with torque values of their own. Wiring diagrams trace the electrical system through the body.
