2016 Ford Figo Service and Repair Manual

This factory service and repair manual for the 2016 Ford Figo covers a small front-wheel-drive car sold as both a four-door sedan and a four-door hatchback, with the 1.5L twin-cam inline-four of 92 cubic inches as its only engine and Energy, Impulse and Titanium as its trims. Shared mechanicals across the two bodies mean the engine, transaxle and suspension chapters serve both, while the body, closure and rear electrical sections differ between the notchback and the hatch.

Engines covered

• 1.5L inline-four (92 cu in) — DOHC, naturally aspirated, gasoline

Body styles covered

• 4-door sedan
• 4-door hatchback

Trims covered

• Energy
• Impulse
• Titanium

Known issues on the 2016 Figo. Open recalls can be checked by VIN on NHTSA's recall lookup. The manual covers the 1.5L DOHC four with its timing, fuel injection, ignition and cooling procedures, the clutch and transaxle behind it, the strut and torsion beam suspension, the steering and hydraulic brake systems, and the wiring diagrams and diagnostics for both body styles.
