2015 Yamaha DRIVE ADVENTURER SPORT 2+2 (48V - DC MOTOR) Service and Repair Manual

$18.00 USD
Digital manual — nothing ships
Matched to your exact vehicle
Money-back guarantee, pay once
4.5 · Trusted by 800+ mechanics & DIYers
Buy 2+ manuals, save 20% Discount applied automatically at checkout
20% off

YDREX5_SPORT is the 2015 DC-motor Drive Adventurer Sport 2+2, and it is covered by LIT-19616-29-15.

That is the same volume Yamaha used for the AC cars, which tells you how closely related the 2015 to 2018 Drive models are. Its fitment reaches the Adventurer One in DC and EFI forms, the Adventurer Sport in AC, DC and EFI trim, the AC-motor Sport 2+2, the Concierge 4 and 6 in both drives, the Drive Fleet in AC, carburetted and EFI versions, and the Drive PTV range.

Principal sections

  • DC motor, controller and 48V battery service
  • Brakes, steering and suspension
  • Body, seats and trim
  • Wiring diagrams and electrical diagnosis

Confirm YDREX5_SPORT on the car; the manual number is LIT-19616-29-15.
