2014 Yamaha DRIVE PTV (48V - DC MOTOR) Service and Repair Manual

$18.00 USD
Digital manual — nothing ships
Matched to your exact vehicle
Money-back guarantee, pay once
4.5 · Trusted by 800+ mechanics & DIYers
Buy 2+ manuals, save 20% Discount applied automatically at checkout
20% off

LIT-19616-29-12 is the book to quote for the 2014 DRIVE PTV with the 48-volt DC motor, model code YDREX4_PTV.

This is a later volume than the one used for the earlier Drive cars, and its coverage reaches across the 2014 and 2017 model years. Nine machines share it, including the ADVENTURER ONE (EFI), the ADVENTURER FAIRWAY LOUNGE in beverage form, the ADVENTURER SPORT in both DC motor and EFI versions, the DRIVE ADVENTURER SPORT 2+2, CONCIERGE 4 and 6 on the DC motor, the DRIVE FLEET (EFI) and the DRIVE PTV (EFI).

The chapters follow the way the car is actually worked on: inspection and adjustment first, then electrical testing with the expected values, motor and controller service, rear axle, brakes, steering, suspension, charging and body. Wiring diagrams are included at full size.

YDREX4_PTV is the code to verify on the car, as the gas and electric variants share sheet metal but very little else.
