2014 Mercedes-Benz CLS500 Service and Repair Manual

This factory service and repair manual for the 2014 Mercedes-Benz CLS500 serves a car whose engine is a 4.7L V8 of 285 cubic inches, with double overhead cams, turbocharged and burning gasoline. Behind that engine sits a four-door sedan body in a lone Base trim. The manual gives torque values, specifications and wiring diagrams for the engine, drivetrain, chassis and body electrical systems.

Engines covered

• 4.7L V8 (285 cu in) — DOHC, turbocharged, gasoline

Body styles covered

• 4-door sedan

Trims covered

• Base

Known issues on the 2014 CLS500. The 2014 CLS500's V8 uses double overhead camshafts, so any job that disturbs the timing drive, the camshafts or the cylinder heads has to go back together at exact settings. The manual gives procedures for that work, specifications for camshaft position and torque values for head and timing hardware, and provides diagnostics and wiring diagrams for the camshaft and crankshaft sensors that the turbocharged engine relies on.
