2013 Yamaha ROYAL STAR VENTURE S Service and Repair Manual

$18.00 USD
Digital manual — nothing ships
Matched to your exact vehicle
Money-back guarantee, pay once
4.5 · Trusted by 800+ mechanics & DIYers
Buy 2+ manuals, save 20% Discount applied automatically at checkout
20% off

This one is narrow rather than broad. Yamaha LIT-11616-RS-21 is written for the 2013 model year alone, and the Royal Star Venture S for that year carries model code XVZ13TFSD.

A single-year manual has an advantage worth noting: nothing in the specification tables belongs to another machine, so there is no risk of taking a torque figure or a clearance meant for a sibling model. Every value in it applies to the bike described on the cover.

The content is factory issue. Assemblies are dismantled and rebuilt in the order Yamaha specified. Inspections give you something to measure and a service limit to measure against. Fasteners have torque values. The electrical chapters include the complete wiring diagrams, and the troubleshooting material is organised so that you start from the fault as it presents itself.

Confirm XVZ13TFSD against the code on your frame, and quote LIT-11616-RS-21 if you need to verify what you are buying.
