2013 Yamaha RHINO Service and Repair Manual

2013 is the last model year inside LIT-11616-RH-70, Yamaha's service book for the RHINO. The machine built that year carries the code YXR7FDGR, and the same volume covers 2009, 2011 and 2012 along with the RHINO 700.

Everything needed for serious work is in it: specifications, the periodic maintenance schedule, engine service with disassembly order and inspection measurements, transmission and differential work, steering, suspension and brake procedures, torque figures, wiring diagrams paired with component test values, and troubleshooting arranged by symptom.

For a final-year machine the inspection limits are the section to lean on, since they tell you what can still be reused. Confirm YXR7FDGR on the frame before ordering, and quote LIT-11616-RH-70 when you need a parts department to verify coverage. Read the year and model callouts as you go — four years share this text.
