2013 Yamaha DRIVE CONCIERGE 4 (48V - DC MOTOR) Service and Repair Manual

$18.00 USD
Digital manual — nothing ships
Matched to your exact vehicle
Money-back guarantee, pay once
4.5 · Trusted by 800+ mechanics & DIYers
Buy 2+ manuals, save 20% Discount applied automatically at checkout
20% off

Code YDREX4_PTV4 identifies the 2013 Drive Concierge 4 with the 48-volt DC motor. Its repair text closes out LIT-19616-JC-01, the volume that opened with the 2010 cars.

Also inside are the DC-motor Adventurer Sport 2+2, the carburetted Concierge 4, the Concierge 6 in both drives, the Drive Fleet in DC and EFI forms and the Drive PTV family, so one book covers a mixed yard of these cars.

Procedures follow the factory's own order and stop short of guesswork: measure, compare against the published limit, then repair or replace. The drive, battery, brake, steering, suspension and body sections each carry their torque figures, and the wiring diagrams are specific to the cars covered.

Verify YDREX4_PTV4 against your frame plate and quote LIT-19616-JC-01 when referring to the manual.
