2013 Yamaha DRIVE ADVENTURER SPORT 2+2 (48V - DC MOTOR) Service and Repair Manual

$18.00 USD
Digital manual — nothing ships
Matched to your exact vehicle
Money-back guarantee, pay once
4.5 · Trusted by 800+ mechanics & DIYers
Buy 2+ manuals, save 20% Discount applied automatically at checkout
20% off

A 2013 Drive Adventurer Sport 2+2 with the 48-volt DC motor carries the code YDREX4_SPORT, and its service manual is LIT-19616-JC-01.

Yamaha wrote that volume for the 2010 to 2013 Drive cars as a group. Also inside are the Concierge 4 and Concierge 6 in DC motor and carburetted forms, the Drive Fleet in DC and EFI trim, and the Drive PTV in its base, DC motor, carburetted and EFI versions.

The DC drive chapters deal with the motor, solenoid, controller and 48V battery bank, including the measurements that separate a tired pack from a wiring fault. Chassis, brake, steering and suspension procedures follow the factory sequence, and the wiring diagrams cover the car as built.

Confirm YDREX4_SPORT on your data plate and note LIT-19616-JC-01 as the reference number.
