2013 Seat Altea XL Service and Repair Manual

This factory service and repair manual for the 2013 Seat Altea XL is written for the XL Style trim of this four-door mini passenger van. Its engine, a 1.8L inline-four, combines turbocharging with double overhead camshafts, displaces 110 cubic inches and burns gasoline. Specifications and procedures for the engine and fuel system are joined by ignition and cooling diagnostics, torque values for the transmission and chassis, and wiring diagrams for the electrical system.

Engines covered

• 1.8L inline-four (110 cu in) — DOHC, turbocharged, gasoline

Body styles covered

• 4-door mini passenger van

Trims covered

• XL Style

Known issues on the 2013 Altea XL. The manual provides wiring diagrams for the electrical system of the 2013 Altea XL together with diagnostics for the turbocharged 1.8L engine and its fuel system, ignition and cooling. For the transmission, drivetrain, brakes, suspension and steering of the mini passenger van it gives procedures and torque values, and the DOHC engine's specifications are included for the XL Style trim.
