2012 Yamaha RHINO Service and Repair Manual

Code YXR7FBGR, model year 2012. The factory service reference is LIT-11616-RH-70, a Yamaha volume covering 2009, 2011, 2012 and 2013, with the RHINO 700 included in its scope.

On a side-by-side that sees real work, the sections earning their keep are the drive-train and chassis chapters — differentials, shafts, suspension, brakes — and the electrical diagnosis material, where the wiring diagrams and expected readings turn a vague fault into a measurement. Engine service is there in full, with wear limits. Torque specifications run throughout, placed with the assemblies rather than gathered at the back.

Fitment: confirm YXR7FBGR on the machine, and note LIT-11616-RH-70 as the literature number. Where a specification differs between the years or between the RHINO and RHINO 700, Yamaha marks it in the text, so read the annotation before applying the number.
