2012 Yamaha DRIVE PTV (48V - DC MOTOR) Service and Repair Manual

$18.00 USD
Digital manual — nothing ships
Matched to your exact vehicle
Money-back guarantee, pay once
4.5 · Trusted by 800+ mechanics & DIYers
Buy 2+ manuals, save 20% Discount applied automatically at checkout
20% off

Model code YDREX2_PTV identifies the 2012 DRIVE PTV built around the 48-volt DC motor, and the book that services it is Yamaha LIT-19616-JC-01.

One manual was written for the whole Drive run, so 2010, 2011, 2012 and 2013 cars are treated together, with year-specific notes called out where a component changed. That matters on a car this age, which may well have earlier or later parts fitted to it by now.

Coverage runs through the DC motor and its controller, the solenoid and main harness, rear axle and differential, front suspension and steering, the mechanical brakes, the charger, and the body and seat hardware. Diagnostic sequences are written as tests with expected readings instead of guesswork, and torque values appear in the assembly step where they apply.

The same volume serves the DRIVE FLEET, CONCIERGE 4 and 6, ADVENTURER SPORT 2+2 and the CARB and EFI PTV cars. Confirm YDREX2_PTV on your data plate before ordering.
