2012 BMW 535i GT xDrive Service and Repair Manual

This factory service and repair manual for the 2012 BMW 535i GT xDrive rests on a single specification and follows it exactly: 3.0 liters of turbocharged inline-six, double overhead camshafts, gasoline, driving all four wheels beneath a four-door hatchback body sold in Base form alone. That narrowness helps on the lift, because a torque figure or a clearance quoted here needs no cross-checking against a second displacement, and the wiring diagrams describe one harness rather than a set of optional builds layered on top of each other.

Engines covered

• 3.0L inline-six — DOHC, turbocharged, gasoline

Body styles covered

• 4-door hatchback

Trims covered

• Base

Known issues on the 2012 535i GT xDrive. Coverage is arranged system by system, which matters on a car that combines a turbocharged six with all-wheel drive and a large rear hatch. The engine sections carry the timing drive, valve gear and boost control specifications; the driveline sections carry the transfer case, propeller shaft and final drive; and the body sections carry the hatch, its latch and the structure around it. Diagnostic charts and circuit diagrams accompany each, so a fault can be worked from symptom to component rather than by replacement.
