2011 Yamaha RHINO Service and Repair Manual

$18.00 USD
Digital manual — nothing ships
Matched to your exact vehicle
Money-back guarantee, pay once
4.5 · Trusted by 800+ mechanics & DIYers
Buy 2+ manuals, save 20% Discount applied automatically at checkout
20% off

Yamaha's LIT-11616-RH-70 is the service manual behind the 2011 RHINO, code YXR7FAGR. Its coverage reaches across 2009, 2011, 2012 and 2013, and it takes in the RHINO 700 as well as the machine on this page.

Content is what a dealer technician would work from. Specifications and maintenance intervals open it. Engine service follows, in Yamaha's disassembly order and with the inspection limits used to judge components. Then transmission, drive shafts and differentials; steering, suspension and brakes; torque specifications with each assembly; wiring diagrams with electrical test values; and troubleshooting keyed to symptoms.

Because the book spans four model years and two model names, check the callouts beside any figure before you use it. Start by confirming YXR7FAGR on your machine, and note LIT-11616-RH-70 for parts enquiries — the parts counter works from the same number.
