2011 Yamaha DRIVE PTV (CARB) Service and Repair Manual

Owners of a 2011 carburetted DRIVE PTV need Yamaha LIT-19616-JC-01. The model code is DRIVE_YDRAX_PTV.

Yamaha's Drive manual was written once and used for four model years, 2010 to 2013. Nine other Drive machines share its pages, so a fleet running a mix of CARB, EFI and 48V DC motor cars can be serviced from the single reference.

What the chapters cover

• Maintenance schedule, inspections and adjustments
• Carburettor, fuel delivery and ignition
• Engine service with clearances and torque figures
• Clutch, belt and transaxle
• Brakes, steering, front and rear suspension
• Electrical testing and wiring diagrams

Specifications are quoted as Yamaha measured them, with the tolerance ranges a technician checks against rather than rounded numbers. DRIVE_YDRAX_PTV should appear on the car before you rely on any of it.
