2011 Yamaha DRIVE PTV (48V - DC MOTOR) Service and Repair Manual

$18.00 USD
Digital manual — nothing ships
Matched to your exact vehicle
Money-back guarantee, pay once
4.5 · Trusted by 800+ mechanics & DIYers
Buy 2+ manuals, save 20% Discount applied automatically at checkout
20% off

Yamaha wrote a single service book for the Drive generation of golf cars, and the 2011 DRIVE PTV with the 48-volt DC motor sits inside it under model code DRIVE_YDREX_PTV. The part number on the spine is LIT-19616-JC-01.

Because that one volume carries the 2010 through 2013 model years, the procedures account for the small revisions Yamaha made across four seasons rather than freezing one year in place.

Other machines in the same book

  • DRIVE PTV, plus the CARB and EFI versions
  • DRIVE FLEET in 48V DC motor and EFI form
  • DRIVE CONCIERGE 4 and CONCIERGE 6, motor and CARB
  • DRIVE ADVENTURER SPORT 2+2 (48V - DC MOTOR)

Inside are the specifications, torque figures, wiring diagrams and disassembly steps the Yamaha dealer network worked from: motor and controller testing, brake and steering service, rear axle, suspension, body panels and the charging circuit. Check DRIVE_YDREX_PTV against the plate on your car first.
