2011 Yamaha DRIVE CONCIERGE 4 (48V - DC MOTOR) Service and Repair M...
LIT-19616-JC-01 is the factory manual behind the 2011 Drive Concierge 4, DC motor, code YDREXSVS_PTV4.
Four model years share it, 2010 to 2013, along with the DC-motor Adventurer Sport 2+2, the carburetted Concierge 4, both Concierge 6 versions, the Drive Fleet in DC and EFI trim, and the Drive PTV range in base, DC, carburetted and EFI forms.
The electrical chapters are the ones a Concierge owner reaches for most, and they include the diagrams and the measured checks that distinguish a failing motor from a controller or a worn pack. Mechanical sections cover brakes, steering, suspension and the body and seating, each with the factory's torque figures.
Read YDREXSVS_PTV4 on the car to confirm the match; the part number is LIT-19616-JC-01.
