2010 Yamaha DRIVE PTV (CARB) Service and Repair Manual

The 2010 DRIVE PTV in carburetted form is stamped YDRA3X_PTV, and Yamaha covers it in LIT-19616-JC-01.

That book opens the Drive series: 2010 is its first model year, and it continues through 2013, so the revisions made during the run are documented in one place. Ten machines fall under it, from the DRIVE FLEET and CONCIERGE cars to the ADVENTURER SPORT 2+2 and the DC motor and EFI PTV models.

On a carburetted car the sections you will reach for most are fuel system service, the carburettor itself, ignition, the starter generator, clutch and belt work, and the transaxle. All of it is here with the factory torque figures, clearances and adjustment procedures, along with the wiring diagrams and the maintenance schedule.

Before ordering, read the plate and confirm YDRA3X_PTV. The CARB, EFI and electric versions are serviced differently, and the code is the only reliable way to tell which set of procedures applies.
