2010 Yamaha DRIVE PTV (48V - DC MOTOR) Service and Repair Manual

$18.00 USD
Digital manual — nothing ships
Matched to your exact vehicle
Money-back guarantee, pay once
4.5 · Trusted by 800+ mechanics & DIYers
Buy 2+ manuals, save 20% Discount applied automatically at checkout
20% off

A 2010 Drive PTV with the 48-volt DC motor is coded YDRE3_PTV, and its service reference is LIT-19616-JC-01.

Yamaha kept that volume current from 2010 to 2013 and used it for the DC Adventurer Sport 2+2, the Concierge 4 and 6 in DC and carburetted forms, the Drive Fleet in DC and EFI trim, the base Drive PTV, and the carburetted and EFI PTV models.

Electric PTV work centres on the motor, solenoid, controller and battery pack, and each is given test values rather than vague advice. The chassis chapters cover brakes, steering, suspension and the body, with torque figures where fasteners are critical, and the wiring diagrams suit these cars as built.

Confirm the YDRE3_PTV code on your frame plate, then order against LIT-19616-JC-01.
