2010 Yamaha DRIVE CONCIERGE 6 (48V - DC MOTOR) Service and Repair M...
LIT-19616-JC-01 carries the service information for the 2010 Drive Concierge 6, DC motor, model code YDREX3SVL_PTV6.
The volume spans 2010 to 2013 and covers the sibling cars of that era: the DC-motor Adventurer Sport 2+2, the Concierge 4 in DC and carburetted forms, the carburetted Concierge 6, the Drive Fleet in DC and EFI trim, and the Drive PTV range.
Service on a six-seat car touches the same drive and chassis hardware as the shorter models, with additional body and seat structure, and the manual covers both. Motor and controller diagnosis, 48V battery and charging procedures, brakes, steering and suspension all appear with their inspection limits, and the wiring diagrams are drawn for these cars specifically.
Check that your frame plate reads YDREX3SVL_PTV6 before ordering LIT-19616-JC-01.
