2010 Yamaha DRIVE CONCIERGE 4 (48V - DC MOTOR) Service and Repair Manual

$18.00 USD
Digital manual — nothing ships
Matched to your exact vehicle
Money-back guarantee, pay once
4.5 · Trusted by 800+ mechanics & DIYers
Buy 2+ manuals, save 20% Discount applied automatically at checkout
20% off

From 2010 the Drive Concierge 4 in DC-motor form, code YDREX3SVS_PTV4, is documented in LIT-19616-JC-01.

That book carries the 2010 to 2013 Drive cars together: the DC-motor Adventurer Sport 2+2, the carburetted Concierge 4, the Concierge 6 in DC and carburetted trim, the Drive Fleet in DC and EFI forms, and the Drive PTV in base, DC, carburetted and EFI versions.

For a four-seat car most of the service work is chassis and drive, and the manual treats both in detail: motor, solenoid and controller checks, 48V battery and charger procedures, brake adjustment and overhaul, steering, suspension, and the rear seat structure. Torque values and inspection limits sit with the steps.

Confirm YDREX3SVS_PTV4 on the frame plate before ordering LIT-19616-JC-01.
