2009 Chevrolet W5500HD Tiltmaster Service and Repair Manual

This factory service and repair manual for the 2009 Chevrolet W5500HD Tiltmaster gives a technician the numbers a medium-duty diesel job depends on. The engine is an inline-four of 5.2 liters and 317 cubic inches, turbocharged, and the truck is cataloged as W5S042. Because the engine bay holds one configuration, the diagnostic trees do not open with a question about which unit is fitted — they open on the symptom and work through the fuel, air, cooling and electrical systems attached to it.

Engines covered

• 5.2L inline-four (317 cu in) — turbocharged, diesel

Trims covered

• W5S042

Known issues on the 2009 W5500HD Tiltmaster. The manual covers procedures, specifications, torque values, wiring diagrams and diagnostics: for the turbocharged 317-cubic-inch four, for the driveline that carries its output, and for the brake, steering and suspension hardware underneath. It is reference material for the work.
