2008 Yamaha G27-AF "UMAX LIGHTY DUTY" (CARB) Service and Repair Manual

$18.00 USD
Digital manual — nothing ships
Matched to your exact vehicle
Money-back guarantee, pay once
4.5 · Trusted by 800+ mechanics & DIYers
Buy 2+ manuals, save 20% Discount applied automatically at checkout
20% off

Part number LIT-19616-G2-70 is the Yamaha service manual that covers the G27-AF, the carbureted light-duty UMAX built for 2008 and identified by the code G27AF.

Fitment

  • Model code: G27AF
  • Yamaha part number: LIT-19616-G2-70
  • Model years in the book: 2004 to 2009

Because one volume was written for the family, the same pages also address the G27-AC, G27-AE and G27-AZ, the 48-volt DC-motor G27-EC through G27-EZ cars, and the G28 UMAX MEDIUM DUTY II series. Differences between those variants are flagged in the procedures where they matter.

The manual is written for someone doing the work: disassembly order, clearances and torque specifications, adjustment procedures, wiring diagrams and the factory troubleshooting charts. No hobbyist paraphrase sits between you and Yamaha's instructions.
