2008 Yamaha "DRIVE FLEET" - YDRA (CARB) Service and Repai...
Model year 2008 got its own Drive Fleet publication. Yamaha part number LIT-19616-29-09 addresses that single year and the YDRA gas car, with no other models or years folded in, which makes it the cleanest reference available for the car.
Mechanical coverage runs through the engine: valve clearance, carburettor overhaul and adjustment, ignition, fuel delivery and exhaust, with published torque specifications. The drive side covers the primary and secondary clutches, belt condition and the rear axle assembly.
Chassis work includes brake adjustment and shoe service, steering and front suspension, wheel and tyre data, and the body and canopy hardware. Electrical material covers the starter-generator circuit, charging and lighting, drawn as diagrams a meter can be used against.
The YDRA code appears on the car. Match it and the year before ordering.
