2007 Yamaha G22-AE "G-MAX" (CARB) Service and Repair Manual

A 2007 G22-AE G-MAX is the last model year in Yamaha's LIT-19616-22-04, and its identification code is G22AE.

The manual reaches back to 2003 and takes in fifteen variants, which means the carbureted cars, the 48-volt electrics and the G23 UMAX Medium Duty utility models all sit under one part number. For a final-year car the accumulated notes are useful, since some components were revised late in the run.

What to expect inside

• Full engine overhaul with clearance and torque tables
• Carburetor and fuel system service
• Clutch, belt and drive train inspection limits
• Brake, steering and suspension adjustment figures
• Electrical diagnosis with complete wiring diagrams

It is written for someone doing the work, not reading about it, and the factory sequence is preserved throughout.
