2006 Yamaha SX230 Service and Repair Manual

$18.00 USD
Digital manual — nothing ships
Matched to your exact vehicle
Money-back guarantee, pay once
4.5 · Trusted by 800+ mechanics & DIYers
Buy 2+ manuals, save 20% Discount applied automatically at checkout
20% off

SRT1000AE is the 2006 code for this hull. The matching factory manual is LIT-18616-SX-A1, the same volume Yamaha wrote for the 2005 boats, since the two years were handled as one service group.

Also inside: the AR230, AR230 High Output and SX230 High Output. If you have more than one 230-series boat in the family or the shop, that overlap saves you buying twice.

  • Yamaha part number LIT-18616-SX-A1
  • Model years covered: 2005 and 2006
  • Model code: SRT1000AE

Content is written at dealer service level. Torque figures, clearances and wear limits, engine and jet pump teardown and reassembly, fuel and cooling work, full electrical schematics and symptom-driven troubleshooting. Check the code on your plate first; the 230 range used several similar ones and the specifications are not interchangeable between the standard and High Output boats.
