2006 Yamaha SX230 HIGH OUTPUT Service and Repair Manual

$18.00 USD
Digital manual — nothing ships
Matched to your exact vehicle
Money-back guarantee, pay once
4.5 · Trusted by 800+ mechanics & DIYers
Buy 2+ manuals, save 20% Discount applied automatically at checkout
20% off

By 2006 Yamaha had folded the High Output boat back into the combined 230-series manual, LIT-18616-SX-A1. It covers the 2005 and 2006 years and also documents the AR230, the AR230 High Output and the standard SX230.

Your code here is SRT1100AE. That single string is what separates this boat from the others in the same book, so verify it on the plate first.

What you can expect to do with it

Rebuild the jet pump to spec. Trace an electrical fault through a proper wiring diagram instead of guessing. Set fasteners to the torque Yamaha specified rather than by feel. Work through a no-start or overheat condition using the factory diagnostic charts.

It is service documentation, complete with clearances and wear limits, written for someone with tools in hand and the boat on a trailer.
