2006 Yamaha ROAD STAR WARRIOR Service and Repair Manual

From 2006 the Warrior moved onto a new manual, LIT-11616-RS-W1, and the 2006 bike is listed there under model code XV17PCV.

This edition covers the 2006 through 2009 model years and gathers in the Midnight Warrior, the Road Star Midnight Warrior and the Warrior. If you have been working from the earlier RS-W0 book, this is the one that supersedes it for these years; the part number is the cleanest way to tell the two apart when you are buying.

Inside

• Factory tightening torques and service limits
• Disassembly and reassembly in the intended sequence
• Inspection criteria for reuse or replacement
• Complete wiring diagrams
• Symptom-based troubleshooting

As always, check XV17PCV against the code on your own frame before treating a specification as yours.
