2006 Yamaha G22 G-MAX (CARB) Service and Repair Manual

LIT-19616-22-04 is the factory service manual behind the 2006 carbureted G22 G-MAX. Its model code is G22AD.

That number is shared across a five-year run, 2003 to 2007, and fifteen variants, since Yamaha documented the gas cars, the 48-volt electrics and the G23 UMAX Medium Duty utility models in one book. A 2006 car is well into the run, and the manual's year notes matter when a part was revised mid-production.

Practical use

• Verify G22AD on the frame plate before ordering
• Work the carburetor and valve procedures to the printed clearances
• Use the wiring diagrams for starting and charging faults

Engine overhaul, fuel system, clutches and drive, brake adjustment, steering, suspension, frame, body and electrical diagnosis are all present, in the order a technician would take them.
