2006 Yamaha G22-ED "G-MAX" (48V - DC MOTOR) Service and R...
Code G22ED belongs to the 2006 G22-ED G-MAX on the 48-volt DC motor, and LIT-19616-22-04 is the manual that goes with it.
Yamaha's consolidation of this platform put fifteen variants and the 2003 to 2007 model years into one volume, gas and electric cars together with the G23 UMAX Medium Duty utility models. Where a component changed between seasons the manual says which years it applies to.
Electrical chapters give the diagnostic order for a battery car, along with the test values for solenoid, controller, switches and motor, and the wiring diagrams are drawn to the production harness rather than simplified.
Mechanical sections cover rear axle overhaul, brake adjustment, steering, front suspension, wheels, frame and bodywork, each with the factory clearance and torque figures. It is written as a sequence of steps with measurements, which is how the work actually goes.
