2006 Yamaha AR230 High Output Service and Repair Manual

By 2006 the High Output boat had moved into the shared book. The 2006 AR230 High Output, code SRT1100BE, is covered by Yamaha LIT-18616-SX-A1.

That manual runs across 2005 and 2006 and also documents the AR230, the SX230 and the SX230 High Output. Four closely related boats in one volume means the specification tables carry several rows for the same procedure, and SRT1100BE is how you pick yours.

Engine service is laid out in factory order with disassembly steps, measurement points, wear limits and reassembly torque. Jet pump work covers impeller and wear ring clearance, nozzle and reverse gate adjustment. Fuel, cooling and exhaust systems follow, then bilge, hull and deck fittings, then the electrical chapter with its wiring diagrams and component test values for tracing faults to their source.
