2005 Yamaha ROAD STAR Service and Repair Manual

Part number LIT-11616-RS-00 is the book you want for a 2005 Road Star, and XV17AT is the code that identifies that machine within it.

The same volume serves four bikes across two years: base Road Star, Road Star Midnight, Road Star Silverado and Road Star Midnight Silverado, for 2004 and 2005. The mechanical package is common to all of them, so Yamaha wrote one set of procedures and noted the trim-specific items where they arise, such as bodywork and fitted equipment.

Coverage

• Scheduled maintenance intervals and tune-up specifications
• Engine removal, valve train, clutch and transmission with torque figures
• Fuel, ignition, charging and starting systems
• Front and rear suspension, wheels, brakes and belt final drive
• Complete wiring diagram plus circuit-by-circuit troubleshooting

Confirm the XV17AT code on the frame and the LIT-11616-RS-00 part number before ordering.
