2004 Yamaha G22-AZ "G-MA"X (CARB) Service and Repair Manual

Listed with a typographical quirk in the model name, the 2004 G22-AZ G-MAX is nonetheless a straightforward carbureted car, coded G22AZ and documented in LIT-19616-22-04.

Yamaha gathered 2003 through 2007 into this manual, fifteen variants in total, so the electric G22 cars and the G23 UMAX Medium Duty utility models share the binding with the gas G-MAX. Shared systems are written once, and where a year differs the text says so.

The engine chapters cover disassembly and measurement in the factory order, with valve, cylinder and piston limits given as figures rather than descriptions. Carburetor work is detailed. The drive train section handles clutch and belt inspection, and the brake chapter gives free play and lining thickness.

Steering, suspension, wheels, frame, body and a full electrical section with diagrams complete it. Check G22AZ against the frame plate before ordering.
