2003 Yamaha RAPTOR 660 Service and Repair Manual

$18.00 USD
Digital manual — nothing ships
Matched to your exact vehicle
Money-back guarantee, pay once
4.5 · Trusted by 800+ mechanics & DIYers
Buy 2+ manuals, save 20% Discount applied automatically at checkout
20% off

A 2003 RAPTOR 660 reads YFM660RLER on its frame label, and the service manual keyed to it is LIT-11616-RP-66, shared with the 2002, 2004 and 2005 machines.

Working from the factory text keeps you honest about measurement. Before a piston goes back in the bore there is a clearance to check; before a clutch pack is reused there is a thickness to verify; before a chain is adjusted there is a slack figure to hit. The manual supplies each one.

Cooling system service, valve clearance checks and suspension adjustment are treated the same way, each with the figure Yamaha specified rather than a range. It also covers the jobs nobody plans for, with symptom-led troubleshooting for starting, running and charging problems, and the wiring diagram needed to follow it.

Where the four years differ, the tables say which figure applies. Read the column for YFM660RLER.
